TRIO UV 10100 Water Sterilisation System
Combines filtration, purification and UV sterilisation in a single system for high-flow facilities.
Technical specifications
View all- Lamp power
- 95 W
- Max. flow rate
- 5.5 m³/h
- Max. pressure
- 16 bar
- Connection size
- 2”
Request received
Our experts will call you.
Free installation
2+8 Year Warranty
24/7 Technical Support
TRIO UV-C water safety on an industrial scale
The Rainwater TRIO UV 10100 is a high-performance integrated system designed for the hygiene and water safety needs of different sectors. With its three-stage protection, 95 W lamp power, 2” connection and maximum flow rate of 5.5 m³/h, it offers a reliable solution for large-scale applications.
The right position for maximum effect
Positioned as the final stage in multi-stage water purification systems, it inactivates microorganisms without using chemicals.
Triple integrated protection
It increases water safety by combining filtration, purification and sterilisation in a single housing.
Industrial applications
Suitable for hotels, restaurants, cafés, apartment buildings, housing estates, agricultural applications and general industrial facilities.
High-power UV-C lamp
With 95 W of lamp power, it supports bacteriological safety under high-flow operating conditions.
Highlights
UV-C sterilisation
The water passes through UV-C light; microorganisms are inactivated without the use of chemicals.
Quartz support system
A spring-loaded support holds the quartz sleeve in place and protects it during transport.
TRIO UV 10100 Water Sterilisation System
Adding value to your life with certification to international standards
The confidence of flawless quality: freshness and peace of mind for everyday life.
CE certificate
FDA certificate
Water Quality
TÜV Cert ISO 14001
NSF certificate- TÜV Cert ISO 9001
Düzen Norwest
Hacettepe University
Istanbul Technical University
Our systems use PARKER – LIQUIFIT – LEGRIS brand components and comply with the US Food and Drug Administration (FDA) regulations, CFR 21.
Product description
Well, rain or tank water may carry a risk of bacteria and viruses; mains water can also become contaminated in building plumbing and storage tanks. The Rainwater TRIO UV 10100 is a system that sterilises water with UV-C light without using chemicals; it does not change the taste or odour of the water and creates no by-products.
Who is the Rainwater TRIO UV 10100 for?
Apartment buildings and housing estates, hotels, restaurants, cafés, social and sports facilities, agriculture and livestock applications, and sites that use rain or well water. It sterilises up to 5.5 m³ of water per hour (at a dose of 25 mJ/cm²).
How does it work?
The water passes through a treatment chamber containing a 95 W amalgam UV lamp; the UV-C light inactivates microorganisms by preventing them from reproducing. The TRIO system combines three processes in a single integrated system: mechanical filters trap sand, sediment, rust and suspended matter, activated carbon provides pre-filtration, and the UV-C unit then inactivates any remaining bacteria and viruses without using chemicals.
Technical data
- Connection size: 2”
- Maximum flow rate (25 mJ/cm²): 5.5 m³/h
- Lamp power: 95 W
- Maximum operating pressure: 16 bar
- Maximum temperature: 50 °C
- UV transmittance (min.): 90%
Installation and maintenance
It is installed on the water inlet line. The UV lamp is replaced once a year and the quartz sleeve on average every 5 years. For maintenance, you can submit a request through the technical service form.
Technical specifications
Capacity
- Max. flow rate (at 25 mJ/cm²)
- 5.5 m³/h
Purification
- UV transmittance (min.)
- %90
Power and size
- Lamp power
- 95 W
- Weight
- 29.3 kg
- Connection size
- 2”
- Max. operating pressure
- 16 bar
- Max. operating temperature
- 50 °C
General
- Distributor
- Rainwater Dış Tic. San. ve Tic. A.Ş.
Let's talk about TRIO UV 10100
Our water treatment experts are here for you.
Request received
Our experts will call you.
Frequently asked questions
What does the Rainwater TRIO UV 10100 do?
It sterilises water with UV-C light, inactivating microorganisms such as bacteria and viruses without using chemicals.
Does UV change the taste of the water?
No. UV sterilisation involves no chemicals; it does not change the taste or odour of the water and creates no harmful by-products.
What is its flow rate?
At a dose of 25 mJ/cm², it sterilises up to 5.5 m³ of water per hour; the connection size is 2”.
When should the lamp be replaced?
The UV lamp is replaced once a year and the quartz sleeve on average every 5 years.
Is a pre-filter needed?
Yes, it is recommended. Suspended particles prevent UV light from penetrating the water, so mechanical and activated carbon pre-filters are used before the UV unit. In DUO and TRIO systems, the pre-filter is built into the system.
